.IMPA Code: 330621
Compressed Air/Electric Safety Lights
Explosion-proof, high powered compressed air driven lamp, commonly used in the oil and petrochemicals industries,
for tank cleaning and pipeline inspections, offering a safer alternative to low voltage lighting in dangerously wet
conditions as well as where flammable gases and vapours can accumulate in confined spaces.
Unit Per Set
| CODE | 33 06 21 | 33 06 23 | ||
| Model | ALM-100P | ALI-100P | ||
| Type | Suspension | |||
| Lamp | Mercury lamp HF-100X E-26 |
Incandescent lamp IL-100 115V E-26 |
||
| Air source | 4.5 – 8 kgf/cm² | |||
| Air consumption | 600 NL/min. | |||
| Main Material | Brass (Non-spark) | |||
| Size & Weight | H 395 mm x D 175 mm, 10.5 kgs | |||
| Approval | H.K. / L.R. / B.V. | |||
Explosion-proof pneumatic light for cleaning operations of tanker holds, etc. where hazardous gases may exist. Compressed air drAives the generator which is directly connected to a turbine, and further enters the switch chamber which causes the lamp to light by activating a differential pressure switch
