IMPA:370422
Navigation Lights
All lights comply with the requirements of “Convention on the International Regulations for Preventing Collisions at Sea, 1972” of IMCO (Inter-governmental Maritime Consultative Organization). Available with a polycarbonate lens and polycarbonate case or a glass lens and a metal case. Both types meet the regulations for A-2 Class vessels.
Navigation Light Classification
| Class | No. of Light | Application |
|---|---|---|
| A-2 | Double & Single | For vessels of 50 mtr or more in length |
| B-1 | Double & Single | For vessels of 20 mtr or more but less than 50 mtr in length |
| B-2 | Single | For vessels of less than 20 mtr in length |
| B-3 | Single |
Class A-2 Polycarbonate Lens & Case
Red Light
How to order: CODE
ITEM, class A-2, polycarbonate lens & case, NUMBER of LIGHTS
ITEM, class A-2, polycarbonate lens & case, NUMBER of LIGHTS
Unit Per Pc.
| CODE | Item | No. of Light | Project Angle | Visibility (n.m) | Bulb (Watt) | Weight (kgs) |
|---|---|---|---|---|---|---|
| 370421 | Masthead Light, Clear | Double | 225 | Over 6 | 60 | 2.1 |
| 370422 | Side Light, Green (Starboard) | “ | 112.5 | Over 3 | “ | “ |
| 370423 | Side Light, Red (Port) | “ | 112.5 | “ | “ | “ |
| 370424 | Stern Light, Clear | “ | 135 | “ | 40 | “ |
| 370425 | Towing Light | Single | 135 | “ | “ | 1.2 |
| 370426 | White Light (Anchor Light) | “ | 360 | “ | “ | 1.1 |
| 370427 | Red Light (Not Under Command Light) | “ | 360 | “ | 60 | “ |
| 370428 | Green Light | “ | 360 | “ | “ | “ |
