IMPA:611734
Hydraulic Cable Shoe Pliers
For non-insulated terminals.
The following four sizes are available. Please specify the size required when ordering.
Specifications
| Applicable Cable Shoe Size |
Wire mm2 (AWG) | Weight grm | |
|---|---|---|---|
| 14 | 10.52 – 16.78 (6) | 2,000 | |
| 22 | 16.78 – 26.66 (4) | ||
| 38 | 26.66 – 42.42 (2) | ||
| 60 | 42.42 – 60.57 (1/0) | ||
| 61 17 34 | Pliers, cable shoe hydraulic for 10.52 – 60.57 mm2 wire size | Pr. | |
| Torque | 60KN |
| Stroke | 10mm |
| Length | 310mm |
| Oil Capacity | — |
| Crimping Range | 4-70mm2 |
| Pipe Crimping Type | confined pressure |
| Die | 4、6、10、16、25、35、50、70 |
| N.W | 1.7kg |
| G.W | 3kg |
