IMPA Code:750521/750522/750523/750524/750525
| CODE | Size mm |
Dimensions mm | Weight Kgs |
||||
| Face to Face |
Flange Diam. |
Flange Bolt Hole | |||||
| Pitch | Number | Hole | |||||
| Globe Valve F-7348 | |||||||
| 750521 | 15 | 110 | 95 | 70 | 4 | 15 | 2.96 |
| 750522 | 20 | 120 | 100 | 75 | 4 | 15 | 3.92 |
| 750523 | 25 | 130 | 125 | 90 | 4 | 19 | 5.65 |
| 750524 | 32 | 160 | 135 | 100 | 4 | 19 | 7.2 |
| 750525 | 40 | 180 | 140 | 105 | 4 | 19 | 9.12 |
