Rubber Air Hose Molded & Braided Construction
IMPA:
350101/350102/350103/350104/350105/350106/350107/350108/350109
Rubber Air Hose
Molded & Braided Construction
Black, corrugated or smooth surface, molded and braided construction, for general service.
Image Placeholder
Unit Per Mtr.
| CODE | Nominal Size mm |
Actual Size mm | Braid | Working Pressure kgf/cm² |
Mtr Per Coil |
|
|---|---|---|---|---|---|---|
| I.D. | O.D. | |||||
| 350101 | 6 | 6.3 | 14.5 | 2B | 15 | 100 |
| 350102 | 9 | 9.5 | 18.0 | “ | “ | “ |
| 350103 | 12 | 12.7 | 24.0 | “ | 10 | “ |
| 350104 | 15 | 15.9 | 27.5 | “ | “ | “ |
| 350105 | 19 | 19.0 | 30.5 | “ | “ | “ |
| 350106 | 25 | 25.4 | 38.0 | “ | “ | “ |
| 350107 | 32 | 31.8 | 47.0 | 3B | 7 | “ |
| 350108 | 38 | 38.1 | 53.5 | “ | “ | “ |
| 350109 | 50 | 50.8 | 71.0 | “ | “ | 50 |
| CODE | Nominal Size mm | Actual Size mm | Braid | Working Pressure kgf/cm2 | Mtr Per Coil | |
| I.D. | O.D. | |||||
| 35 01 01 | 6 | 6.3 | 14.5 | 2B | 15 | 100 |
| 35 01 02 | 9 | 9.5 | 18 | “” | “” | “” |
| 35 01 03 | 12 | 12.7 | 24 | “” | “” | “” |
| 35 01 04 | 15 | 15.9 | 27.5 | “” | “” | “” |
| 35 01 05 | 19 | 19 | 30.5 | “” | “” | “” |
| 35 01 06 | 25 | 25.4 | 38 | “” | “” | “” |
| 35 01 07 | 32 | 31.8 | 47 | 3B | 7 | “” |
| 35 01 08 | 38 | 38.1 | 53.5 | “” | “” | “” |
| 35 01 09 | 50 | 50.8 | 71 | “” | “” | 50 |
