Key Features
- All-round light signal for lifeboats, rescue boats and liferafts, improving visual detection during SAR operations
- Available in steady-burning and flashing versions; flashing output of 50–70 flashes per minute
- DC12V / 13W power supply, compatible with standard survival craft battery systems
- Tested to IMO MSC.81(70) for high/low temperature cycling, vibration, oil resistance, rain and watertightness, fire, luminous intensity and chromaticity
- Insulation resistance ≥200Ω for reliable operation in damp, salt-laden marine conditions
- Complies with the LSA Code and holds CCS type approval for use on internationally trading ships
Technical Specifications
| Parameter | Specification |
|---|---|
| Product type | Position indicating light for lifeboat & liferaft |
| Model options | Steady-burning type; flashing type; additional flashing variant |
| Power supply / voltage | DC12V |
| Power consumption | 13W |
| Flashing frequency | 50–70 flashes/min (flashing versions) |
| Insulation resistance | ≥200Ω |
| Compliance | LSA Code; IMO MSC.81(70) |
| Approval | CCS type approval |
| Environmental tests | High/low temperature cycling, vibration, oil resistance, rain & watertightness, fire, luminous intensity, chromaticity (per MSC.81(70)) |
| Application | Upper part of lifeboats, rescue boats and liferafts |
Frequently Asked Questions
Can you supply the full safety equipment range, not just this position indicating light?
Yes. ALL-K MARINE Ship Store supplies the complete IMPA-coded marine stores range, including safety equipment. You can order this light together with other safety items in one inquiry, and we will quote the whole list with wholesale or retail pricing as appropriate.
What is the minimum order quantity, and do you offer wholesale pricing?
We accept both wholesale and retail orders. There is no strict minimum for retail buyers, while wholesale pricing applies to larger quantities. Send us your required quantity and we will confirm pricing and availability within 24 hours.
Do you ship worldwide, and can you deliver to my ship agent?
Yes. We ship worldwide through established freight forwarders. A portion of our supplies reaches vessels through the customer's local ship agent — provide your agent's details and we will arrange delivery to them on request. We do not claim direct alongside or dock delivery.
What are the voltage and model options for this position indicating light?
The light operates on DC12V at 13W. It is available in a steady-burning version and flashing versions; flashing models pulse at 50–70 flashes per minute. Confirm your required model and voltage when inquiring so we can match your lifeboat or liferaft arrangement.
