Key Features
- High exhaust capacity: 1211–1580 CFM (2058–2682 m³/h) depending on inlet pressure
- Pneumatic drive: requires 38–64 CFM (66–108 m³/h) of compressed air
- 200mm duct size compatible with standard ventilation hoses
- Integrated grounding clamp for static electricity elimination
- Rugged construction for humid, corrosive, and high-temperature environments
- Compact and lightweight for confined space operations
- Low maintenance and high reliability
Technical Specifications
| Specification | Value |
|---|---|
| Duct Size | 200 mm (8 in) |
| Working Pressure | 0.3–0.6 MPa (43–87 psi) |
| Exhaust Volume @ 50 psi (3.45 bar) | 1211 CFM (2058 m³/h) |
| Air Consumption @ 50 psi | 38 CFM (66 m³/h) |
| Exhaust Volume @ 70 psi (4.83 bar) | 1429 CFM (2424 m³/h) |
| Air Consumption @ 70 psi | 53 CFM (90 m³/h) |
| Exhaust Volume @ 90 psi (6.21 bar) | 1580 CFM (2682 m³/h) |
| Air Consumption @ 90 psi | 64 CFM (108 m³/h) |
| Grounding Clamp | Included |
| IMPA Code | 591411 |
Frequently Asked Questions
What is the maximum exhaust capacity of this air mover?
At 90 psi inlet pressure, it delivers up to 1580 CFM (2682 m³/h), making it ideal for rapid ventilation of large tanks.
Can this air mover be used in hazardous areas?
Yes, it features a grounding clamp to eliminate static electricity, making it suitable for potentially explosive atmospheres when used with non-sparking hoses.
What are the air consumption requirements?
It consumes between 38 and 64 CFM (66-108 m³/h) depending on inlet pressure, ensuring efficient use of shipboard compressed air systems.
Is this air mover easy to maintain?
Yes, it is designed for low maintenance with a rugged construction that withstands harsh marine environments, minimizing downtime.
