IMPA Code: 756601/756602/756603/756604/756605/756606/756607/756608/756609/756610/756611
| CODE | DN | Size mm | Kv*-values | Weight kgs |
|||
| φd | L | H | M | ||||
| 756601 | 1/4” | 10 | 45 | 48 | 80 | 4.1 | 0.12 |
| 756602 | 3/8” | 10 | 45 | 48 | 80 | 6.3 | 0.12 |
| 756603 | 1/2” | 15 | 59 | 55 | 105 | 15.5 | 0.22 |
| 756604 | 3/4” | 20 | 69 | 66 | 120 | 31 | 0.36 |
| 756605 | 1” | 25 | 83 | 70 | 120 | 52 | 0.57 |
| 756606 | 1-1/4” | 32 | 94 | 83 | 135 | 100 | 0.89 |
| 756607 | 1-1/2” | 40 | 102 | 93 | 160 | 180 | 1.15 |
| 756608 | 2” | 50 | 124 | 102 | 160 | 350 | 1.77 |
| 756609 | 2-1/2” | 65 | 148 | 143 | 265 | 580 | 3.3 |
| 756610 | 3” | 80 | 171 | 153 | 265 | 1000 | 5.37 |
| 756611 | 4” | 100 | 206 | 187 | 340 | 1550 | 8.24 |
| 754412 | 450 | 535 | 438 | 114 | 877 | 406 | 99 |
| 754413 | 500 | 586 | 477 | 127 | 1008 | 485 | 115 |
| 754414 | 600 | 695 | 560 | 154 | 1180 | 570 | 215 |
